Victron Phoenix Inverter 12/1200

(0 reviews)

12 V 1200 VA pure sine wave inverter with AU outlet and VE.Direct

$ 438.90 - Inc GST 438.9 in stock AUD $ 438.90 Tax Included

This combination does not exist.

ADD TO CART

LawntonIn stock

CapalabaIn stock

Sunshine CoastIn stock

VICTRON

Terms and Conditions

30-day money-back guarantee

Ships in 2-3 Business Days (online only products may differ)

Category: Inverters, RV Inverters

SKU: PIN122121310

Victron Phoenix Inverter 12/1200

Features:

12 V, 1200 VA pure sine wave inverter (1000 W continuous at 25 °C, 2200 W peak)
Australian AS/NZS 3112 power outlet
VE.Direct port for monitoring and configuration (add a VE.Direct Bluetooth dongle for phone access)
ECO mode cuts idle power to about 1 W
Dynamic, load-dependent low-voltage cut-off protects your battery
Remote on/off
High start-up power for motors, pumps and compressors
Up to 91% efficiency

Where to use it

The Phoenix 12/1200 runs 240 V appliances from a 12 V battery in caravans, motorhomes, 4WDs, boats and small off-grid setups: TVs, laptops, coffee machines (within 1000 W), power tools and chargers.

The plug-in AU outlet means no hard wiring is needed on the AC side.

Dimensions

Height	117 mm
Width	232 mm
Depth	327 mm
Weight	7.4 kg

Warranty

5-year warranty
Access to Springers Solar's warranty support team
Authorised Victron dealer

Applications:

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Victron:

Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.

Manual_Phoenix-Inverter-VE.Direct-250VA-1200VA-EN-NL-FR-DE-ES-IT.pdf

Download

Datasheet_Phoenix-Inverter-VE.Direct-250VA-1200VA-EN.pdf

Download

Size the cable and fuse to the inverter's maximum DC current and the cable length. For the Phoenix 12/1200 the battery terminals take cable up to 35 mm². Fit a fuse or circuit breaker close to the battery. Ask our team if you're unsure.

Product Specifications

Cont. power at 25°C	1200VA
Cont. power at 25°C / 40°C	1000 / 850W
Peak power	2200 W
Output AC voltage / frequency (adjustable)	230VAC or 120VAC +/- 3%, 50Hz or 60Hz +/- 0,1%
Input voltage range	9.2 - 17 / 18.4 - 34.0 / 36.8 - 62.0V
DC low shut down (adjustable)	9.3 / 18.6 / 37.2V
Dynamic (load dependent) DC low shut down (fully configurable)	Dynamic cut-off, see https://www.victronenergy.com/live/ve.direct:phoenix-inverters-dynamic-cutoff
DC low restart and alarm (adjustable)	10.9 / 21.8 / 43.6V
Battery charged detect (adjustable)	14.0 / 28.0 / 56.0V
Max. efficiency	91 / 91 / 92%
Zero-load power	7 / 8 / 10W
Default zero-load power in ECO mode (default retry interval: 2.5 s, adjustable)	1 / 1.5 / 3.0W
ECO mode stop and start power setting	Adjustable
Protection	a - f
Operating temperature range	-40 to +65°C (fan-assisted cooling), Derate 1,25% per °C above 40°C
Humidity (non-condensing)	max 95%
Material & Colour	Steel chassis and plastic cover (blue Ral 5012)
Battery-connection	Screw terminals
Maximum cable cross-section	35 / 25 / 25mm2 / AWG2 / 4 / 4
Standard AC outlets	230V: Schuko (CEE 7/4), IEC-320 (male plug included) UK (BS 1363), AU/NZ (AS/NZS 3112) 120V: Nema 5-15R, GFCI
Protection category	IP 21
Weight	7.4kg
Dimensions	117 x 232 x 327mm
Remote on-off	Yes
Automatic transfer switch	Filax
Safety	EN-IEC 60335-1 / EN-IEC 62109-1 / UL 458 (3)
EMC	EN 55014-1 / EN 55014-2 / IEC 61000-6-1 / IEC 61000-6-2 / IEC 61000-6-3
Automotive Directive	ECE R10-4
