Features:
• Marine-Grade On/Off Switch
• Switches Between Isolated Battery Banks
• 275Amps Continuous Rating
| Brand: Victron |
Features:
Victron marine battery switch:
This battery master switch features terminals and heavy-duty plastic construction, making it ideal for marine applications or automotive requirements where the switch is exposed to the weather.
Product Properties:
- Unique ergonomic and aesthetic knob design
- Knobs removable for isolation/safety
- Surface or panel-mounted options provides flexibility when installing
- Meets ISO8846 ignition protection, suitable for use in the engine room
- Suitable for applications up to 48VDC
- 275A max continuous current
- 455A one-minute rating
- 1250A cranking rating
Applocation
More about Victron:
Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.
| Brand | Victron |
Max continuous current: | 275A |
One minute rating: | 455A |
Cranking rating: | 1250A |
Voltage rating: | 48V |
Terminal & hex-nut material: | Tin-plated copper |
Terminal diameter: | 3/8" inch / 9.53mm |
Base material: | Glass fiber reinforced nylon |
Weight (kg): | 0.2 |
Size (mm) LxWxH: | 69.5x76.3x69.5 |
Mounting: | Surface or rear panel mount |
Ignition protected: | ISO8846 / SAE J1171 |
