Enerdrive 12V 190W Solar Panel Silver

Features:
• 190W Monocrystalline Solar Panel
• 1500 x 680 x 35mm
• 5-year warranty

$ 255.00 - Inc GST 255.0 in stock AUD $ 255.00

$ 255.00

Brand

This combination does not exist.

ADD TO CART

Brand: Enerdrive

ENERDRIVE

SKU: ANL050

Category: Solar Panels Fixed Panels

Enerdrive rigid solar panels:

Enerdrive has a range of Mono & Poly Crystalline solar panels from 10 to 200 watts. Each module is typically around 20+vdc open circuit and are well suited to 12v installations (or 24v by series connections of panels).

A fly lead cable is provided for easy connection of the 10 & 20W panels while the larger panels have MC4 compatible solar cable connectors included. Enerdrive stocks a full range of spare cables.

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Enerdrive:

Enerdrive Pty Ltd has been providing independent power systems to the Australian market since 1996. Starting as Advance Trident Limited in 2003 and predominantly servicing the marine industry, ATL saw the huge growth potential in the mobile and recreational vehicle market soon after, and in 2008 ATL Limited morphed into Enerdrive. In recent times Enerdrive has embarked on its own manufacturing program. They saw the need to control their own destiny and produce high-end products that the Australian marketplace was demanding. This program has led to Enerdrive manufacturing their own range of ePOWER AC Battery Chargers & DC2DC Battery Chargers along with Lithium battery systems.

Specifications

Brand

Enerdrive

SP-EN190W-SP-EN190WB-Solar-Spec-Sheet.pdf

Download

Product Specifications

Enerdrive Part Number	SP-EN190W
Max Power Pm(W)	190
Power Tolerance %	± 5%
Max Power Voltage Vm(V)	20.00
Max Power Current Im(A)	9.50
Open Circuit Voltage Voc(V)	24.80
Short Circuit Current Isc(A)	10.07
Max System Voltage (VDC)	1000
Dimensions (mm)	1500 x 680 x 35
Weight (kg)	11.5
Test Conditions	1000W/m² , AM1.5 , 25°C
