Bluesea Battery Terminal Mount Fuse Block Kit

Bluesea Battery Terminal Mount Fuse Block Kit

Provides power to new accessories in your boat or vehicle

$ 75.00 - Inc GST 75.0 in stock AUD $ 75.00

$ 75.00

Brand

This combination does not exist.

ADD TO CART

Brand: Blue Sea Systems

BLUESEA

SKU: ANL050

Category: Circuit Protection Fuse & Fuse Holder Fuse Holder Distribution

Description
Specifications

Blueseas BS-5024 Battery terminal fuse block kit:

Easily add 4 fused circuits to the terminal of a battery. Provides power to new accessories in your boat or vehicle.

Features:

- Mounts on the battery terminal stud

- Screw terminals for securing wires

- Nylon insulated ring terminals included for each screw terminal

- Accepts small format circuit labels

- Insulating cover meets ABYC/USCG insulation requirements

- Ignition Protected–meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment

- Includes a 4-circuit negative busbar

- Includes write on labels

- Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Blue Sea:

Blue Sea Systems designs and manufactures products for marine, emergency vehicle and renewable energy electrical systems in both DC and AC applications. Their products include high-amperage switches, digital meters, solenoids, circuit protection systems, battery chargers, power distribution systems and other high-quality, environmentally robust electrical circuit devices. With distributors and retailers in over 40 countries worldwide, Blue Sea is one of the world’s most trusted marine energy components manufacturers.

Specifications

Brand

Blue Sea Systems

Product Specification

Circuits	4
Maximum Amperage	100A per block 30A per circuit
Maximum Voltage	32V DC
Bus Material	Tin-Plater Copper C11000
Mounting Hole	3/8” (M10) Stud
Screw terminal Torque	18 in-lb (2.03 Nm)
Screw terminal Type	#8-32
Weight	0.50lb (0.23 kg)
