Enerdrive ePRO 24V 80A Battery Charger

(0 reviews)

Features:
• 24V 80A Battery Charger
• 3 Current Outputs
• 5-year warranty

$ 3,039.20 - Inc GST 3039.2 AUD $ 3,039.20 Tax Included

Brand

This combination does not exist.

ADD TO CART

LawntonOnline Only

CapalabaOnline Only

Sunshine CoastOnline Only

Brand: Enerdrive

ENERDRIVE

Terms and Conditions

30-day money-back guarantee

Ships in 2-3 Business Days (online only products may differ)

Category: Battery Chargers, AC Chargers, AC Chargers

SKU: EPBC-2480

Enerdrive EPRO battery chargers:

Enerdrive have a new programmable ePRO battery charger that takes battery charging technology to new heights. The ePRO battery chargers are equipped with the latest power conversion techniques to set new reliability and efficiency standards.

Features of the ePRO programmable battery chargers

The ePRO 12V 90A, 24V 50A and 80A models combine new power conversion techniques and the best available parts with years of power electronics design expertise. The ePRO battery chargers are developed to perform without problems in the most demanding environments. A unique active rectifier output stage ensures unmatched efficiency figures. Combined with active PFC, the ePRO battery chargers are very energy efficient. This will reduce running costs and guarantees a maximum charge current per AC Watt. All ePRO battery chargers are equipped with advanced 4 stage charging algorithms and temperature compensation for optimal battery performance and long lifetimes. Users are also allowed to create a custom charging algorithm for their specific battery, using the “Dashboard” software. ePRO battery chargers are also suitable to charge Lithium Iron Phosphate (LiFePo4) batteries. The standard available TBSLink port enables remote control and readout via the optional TBS Remote Controls. All ePRO battery charger models, are equipped with 3 full current isolated outputs, allowing simultaneous charging of 3 battery banks. Additionally, these models allow up to 6 units to be connected in parallel, reaching charging current levels of up to 540Amps!

ePRO applications

The features and built quality of the ePRO programmable battery chargers allow these chargers to be used in a wide range of applications. Some of these applications include industrial-, marine- and recreational vehicle power systems.

Charger Features:

- Fully programmable

- Robust design

-Universal input with PFC

- 3 full current outputs

- Protected against high temp., short circuit, reverse polarity

- Parallel connectable (up to 6 units)

- Variable speed fan for silent operation

- Intelligent charging algorithms

- Remote on/off and alarm relay connections

- 2 Year Warranty from an Australian company renowned for customer support.

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Enerdrive:

Enerdrive Pty Ltd has been providing independent power systems to the Australian market since 1996. Starting as Advance Trident Limited in 2003 and predominantly servicing the marine industry, ATL saw the huge growth potential in the mobile and recreational vehicle market soon after, and in 2008 ATL Limited morphed into Enerdrive. In recent times Enerdrive has embarked on its own manufacturing program. They saw the need to control their own destiny and produce high-end products that the Australian marketplace was demanding. This program has led to Enerdrive manufacturing their own range of ePOWER AC Battery Chargers & DC2DC Battery Chargers along with Lithium battery systems.

Specifications

Brand

Enerdrive

Datasheet_ePRO-Battery-Charger-UserManual-Ver1-WEB.pdf

Download

Enerdrive-Warranty-Policy-2020.pdf

Download

Product Specification

AC input voltage	180-260Vac
Full load power consumption	2750VA
AC input current (115V/230V)	- / 12A
Total DC output current(1) (4)	80A
Nominal DC output voltage(1)	12Vdc
Number of full current outputs	3 (internally isolated)
Charge characteristic(2)	IUoUoP, intelligent 4-stage, temp. compensated
Standard absorption voltage(2)	28.8Vdc
Standard float voltage(2)	27.0Vdc
Standard equalize voltage(2)	31.6Vdc
Supported battery types(2)	Flooded / Gel / AGM / LiFePO4 / Custom
Recommended battery capacity(3)	160-800Ah
DC current draw (charger off)	< 0.1mA
Operating temp. Range	-10°C…+55°C (humidity max. 90% non condensing)
Storage temp. Range	-20°C…+70°C (humidity max. 90% non condensing)
Cooling	Variable speed fan
ePRO Link enabled	Yes
Protections	Low AC input voltage, output short circuit, high temperature, battery overcharging and reverse polarity (fuse)
Indications	Power on, output current, state of charge, error
DC output connections	4x M8 bolts
AC input connections	Screw terminals
Enclosure body size (HxWxD)	370 x 271 x 132mm
Total weight	6.2kg
Protection class	IP21 (mounted in upright position)
Standards	CE marked. EMC : EN55016-2-1(/A1), EN55016-2- 3(/A1), EN 61000-4-2(3/4/5/6). Safety : EN60335-1, EN60335-2-29 Complies with AS/NZS 60335.2.29 Including Australian deviations.
