Victron Orion-Tr 12/24-15A (360W) Isolated DC-DC Converter

Victron Orion-Tr 12/24-15A (360W) Isolated DC-DC Converter

Features

• 12V to 24V isolated DC-DC converter, 15 A (360 W)
• Galvanically isolated: 200V DC between input, output and case
• Adjustable output voltage; stable output across the input range (buck-boost)
• Remote on/off terminal: no need for a high-current switch
• Short circuit proof
• Connect any number in parallel for more current
• Screw terminals, no special tools needed
• Not intended for battery charging - use an Orion-Tr Smart for that

Where to use it

The Orion-Tr 12/24-15A powers 24V equipment from a 12V supply, for example radios, electronics, pumps and lights in trucks, boats, motorhomes and off-grid systems.

The isolated design keeps the input and output separate, which is preferred on boats and where equipment needs its own clean supply or separate ground.

Dimensions

Warranty

• 5-year warranty
• Access to Springers Solar's warranty support team
• Authorised Victron dealer

Applications:

Marine

RV's

Motor Homes

4WD

Motor Vehicles

More about Victron:

Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.
