Victron 48/6k5/100-50 230V GX MultiPlus-II

Victron 48/6k5/100-50 230V GX MultiPlus-II

(0 reviews)

48 V 6.5 kVA inverter with 100 A battery charger, 50 A transfer switch and integrated GX monitoring system for off-grid power systems

$ 1,887.00 - Inc GST 1887.0 AUD $ 1,887.00 Tax Included

This combination does not exist.

ADD TO CART

LawntonOnline Only

CapalabaOnline Only

Sunshine CoastOnline Only

VICTRON

Terms and Conditions

30-day money-back guarantee

Ships in 2-3 Business Days (online only products may differ)

Category: INVERTER CHARGERS, Inverter Chargers, Victron, Multiplus

SKU: PMP482606000

Victron 48/6k5/100-50 230V GX MultiPlus-II

Features

230 V inverter output
100 A battery charger
50 A transfer switch
Suitable for 48 V systems
Built-in GX device
PowerControl
PowerAssist
UPS functionality
Dual AC outputs
Parallel capability
Three-phase capability
Adaptive 4-stage charging
ESS compatibility
Programmable relay
VE.Bus communication
AES mode
Search mode
Temperature compensation
Anti-islanding
Multi-battery chemistry support

Feature	MultiPlus-II (Standard)	MultiPlus-II GX
Integrated Display	No	Yes (2 x 16 LCD)
Built-in Wi-Fi/Ethernet	No	Yes
Direct BMS-Can Port	No	Yes
Remote Monitoring	Requires external GX	Built-in
Best For	Parallel/Multi-unit builds	Clean, single-unit installs

Where to use it

The Victron MultiPlus-II 48/5000/70-50 GX is the ultimate all-in-one powerhouse for 48 V energy systems, combining a 6kW pure sine wave inverter, a high-capacity 100 A battery charger, and an integrated GX device for professional-grade system management. This sophisticated unit is designed to be the heart of any high-end off-grid home, large RV, or marine power system, offering seamless PowerControl and PowerAssist technology to prevent source overloading while providing an uninterruptible power supply.

With built-in Wi-Fi, Ethernet, and various communication ports, it allows for instant remote monitoring and control via the Victron Remote Management (VRM) portal without the need for additional hardware, making it a streamlined and reliable choice for modern energy storage and backup applications.

Dimensions

Width	320mm
Height	644 mm
Depth	150 mm
Weight	29 kg

Safety features

Galvanic isolation between battery and AC circuits prevents dangerous ground loops and enhances system safety
Comprehensive electronic protection against output short circuits and power overloads to prevent hardware damage
Integrated thermal sensors protect the unit from overheating with fan-assisted cooling for high-load reliability
Advanced battery monitoring prevents damage by shutting down the system during low or high voltage events
Internal protection against 230V AC back-feeding on the inverter output ensures safe electrical operation
Certified to international safety standards including EN-IEC 60335 and EN-IEC 62109 for reliable residential and industrial use

Warranty

5-year warranty
Access to Springers Solar's warranty support team
Authorised Victron dealer

Applications

4WD

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

About Victron

Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.

Manual_2983-MultiPlus-II_GX-pdf-en.pdf

Download

Datasheet_MultiPlus-II-4k5-6k5-GX-EN.pdf

Download

Product Specifications

MultiPlus-II GX 230V 48/6k5/100-50
PowerControl & PowerAssist	Yes
Transfer switch	50 A
Maximum AC input current	50 A
Inverter
DC Input voltage range	38 - 60 V
Output voltage	230 V ± 2%
Output frequency	50 Hz ± 0.1%
Cont. output power at 25°C	6 kW
Cont. output power at 40°C	5 kW
Cont. output power at 65°C	4.6 kW
Time-limited power 1 (cold start)	6.5 kW / 4 h
Time-limited power 2 (cold start)	8 kW / 1 h
Max apparent feed-in power	6 kW
Peak power	11 kW / 1min
Maximum efficiency	96 %
Zero load power	28 W
Zero load power in AES mode	18 W
Zero load power in Search mode	8 W
Charger
AC Input voltage range	187 - 265 V
AC Input frequency range	45 - 65 Hz
Charge voltage 'absorption'	57.6 V
Charge voltage 'float'	55.2 V
Storage mode	52.8 V
Max. battery charge current at 25°C	100 A
Max. battery charge current at 40°C	95 A
Battery temperature sensor	Yes
Compatible battery chemistries	Lithium, Lead-acid, Zinc-Bromine and more
General
Auxiliary output	Yes (32 A)
Interfaces	BMS-Can, USB, Ethernet, VE.Direct, Wi-Fi
External AC current sensor (optional)	50 A or 100 A
Programmable relay	Yes
Protection	a - g
VE.Bus communication port	For parallel and three-phase operation, remote monitoring and system integration
General-purpose communication port	Yes, 2x
Remote on-off	Yes
Operating temperature range	-40°C to +65°C (fan-assisted cooling)
Maximum humidity (non-condensing)	95 %
Maximum altitude	2000 m
Enclosure
Material & Colour	Steel, blue RAL 5012
Protection category	IP21
Battery-connection	M8 bolts
230 V AC connection	Screw terminals 13 mm² (6 AWG)
Weight	29 kg
Dimensions (h x w x d)	644 x 320 x 150 mm
Standards
Safety	EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2
Emission, Immunity	EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Uninterruptible power supply	Pending
Anti-islanding	Pending
