REC 420W Alpha Pure-R Solar Panel
https://www.springers.com.au/shop/rec420-rec-420w-alpha-pure-r-solar-panel-16719 https://www.springers.com.au/web/image/product.template/16719/image_1920?unique=16f8101Features:
• 420W Maximum Power Output
• Advanced Cell Technology
• 25-year Product Warranty
REC
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days
REC 420W Alpha Pure-R Solar Panel
REC PURE ALPHA 405W SOLAR PANEL:
Building on REC's multiple award-winning innovations, the REC Alpha Pure family of solar panels empowers you to take full advantage of solar energy. Packing in cutting-edge technologies to deliver higher power density, stunning aesthetics, and minimal environmental impact – all with the renowned quality of REC – REC Alpha Pure and Pure-R are the solar panels of choice for home solar. How does REC do it and what does it mean for you?
Heterojunction (HJT) cell technology
- No LID = no power loss; you get the power you pay for
- Leading temperature coefficient means more energy as temperature rises
- Higher power for greater savings and accelerated return on investment
- With high power density (watts/m²), REC Alpha Pure and Pure-R panels generate more energy from the same area, getting more from limited spaces
- REC Alpha Pure Series delivers around 16% more power on your roof compared to conventional panels
Advanced cell connection technology
- Increased number of wires greatly improves flow of electricity current
- Eliminating invasive soldering removes risk of cell damage or microcracks for long-lasting high performance
- Stylish looks thanks to thin, barely-visible wires and uniformly black-colored cells
- Full-black variant is a design masterpiece and the most elegant feature for your home
- Solder-free cells
- Environmentally-friendly manufacturing drastically reduces carbon footprint
Gapless cell layout
- Innovative gapless cell layout increases active area of the panel to capture more sunlight
- Boosts power density to impressive 223 watts/m², with panel power reaching 430 Wp
- Higher power in a compact panel size
- Elegant full-black design
Pioneering panel designs
- REC's award-winning and iconic Twin design splits the REC Alpha Pure into two ‘Twin’ sections
- Reduces internal resistance for more power and reliability
- Continued energy production in shaded conditions means you see higher energy yields
- REC Alpha Pure-R takes this further and divides the panel into four sections, producing even more energy in shade
Super-strong frame
- Support bars protect cells and glass from bending under load
- Support bars protect cells and glass from bending under load
- Panels maintain high performance levels over the installation lifetime
- 30 mm frame height makes panel easier to handle
- Frame design allows optimized transportation: more panels/pallet = more panels/container = fewer trucks on the road = more savings
LEAD FREE
- Lead Free
- Lead removed from all panel components, including cell connections, cross connectors and junction box soldering
- No toxic leakage of lead after recycling
- Enables homeowners to boost environmental impact and lower overall carbon footprint even more
Premium solar panel warranty
- 25 year product warranty*: covers panel defects
- 25 year performance warranty: ensures panels perform exactly as they’re expected to – every year for 25 years
- 25 year labor warranty*: gives added protection in case a panel needs to be serviced
- At least 92% of nameplate power in year 25; an industry best
- Unprecedented savings, more economic security, and greater energy autonomy for consumers
- * when installed by a REC Certified Solar Professional installer; part of the REC ProTrust Warranty, such as Springers Solar
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
More about REC:
Founded in 1996, REC Group is an international pioneering solar energy company dedicated to empowering consumers with clean, affordable solar power. As Solar’s Most Trusted, REC is committed to high quality, innovation, and a low carbon footprint in the solar materials and solar panels it manufactures. Headquartered in Norway with operational headquarters in Singapore, REC also has regional hubs in North America, Europe, and Asia-Pacific.
Product Specifications
Cell type: | 80 half-cut REC bifacial, heterojunction cells with lead-free, gapless technology |
Glass: | 0.13 in (3.2 mm) solar glass with anti-reflective surface treatment in accordance with EN 12150 |
Backsheet: | Highly resistant polymer (black) |
Frame: | Anodized aluminum (black) |
Junction box: | 4-part, 4 bypass diodes, lead-free IP68 rated, in accordance with IEC 62790 |
Connectors: | Stäubli MC4 PV-KBT4/KST4 (12 AWG) in accordance with IEC 62852, IP68 only when connected |
Cable: | 12 AWG (4 mm²) PV wire, 67 + 67 in (1.7 + 1.7 m) in accordance with EN 50618 |
Dimensions: | 68.1 x 44.0 x 1.2 in (20.77 ft2 ) / 1730 x 1118 x 30 mm (1.93 m2 ) |
Weight: | 47.4 lbs (21.5 kg) |
Origin: | Made in Singapore |
Power Output - PMAX (Wp) | 420 |
Watt Class Sorting - (W) | 0/+10 |
Nominal Power Voltage - VMPP (V) | 50 |
Nominal Power Current - IMPP (A) | 8.4 |
Open Circuit Voltage - VOC (V) | 59.4 |
Short Circuit Current - ISC (A) | 8.88 |
Power Density (W/ft2) | 20.22 |
Panel Efficiency (%) | 21.8 |
Power Output - PMAX (Wp) | 320 |
Nominal Power Voltage - VMPP (V) | 47.1 |
Open Circuit Voltage - VOC (V) | 56 |
Short Circuit Current - ISC (A) | 7.2 |
Operational temperature: | : -40 ... +85°C |
System voltage: | 1000 V |
Test load (rear): | - 4000 Pa (83.5 lbs/ft2) * |
Series fuse rating: | 25 A |
Reverse current: | 25 A |
