REC 460W Alpha Pure-RX Solar Panel

Features:
• 460W Maximum Power Output
• Advanced Cell Technology
• 25-year Product Warranty

REC

SKU: ANL050

Category: Solar Panels Fixed Panels

REC 460W Alpha Pure-RX Solar Panel

REC’s most powerful residential solar panel, the REC Alpha Pure-RX hits the sweet spot between high power and practical handling, in an elegant full-black design. Reaching 470 W in a compact form factor, it boasts an impressive power density of 226 W/m2, with 22.6% panel efficiency.

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about REC:

Founded in 1996, REC Group is an international pioneering solar energy company dedicated to empowering consumers with clean, affordable solar power. As Solar’s Most Trusted, REC is committed to high quality, innovation, and a low carbon footprint in the solar materials and solar panels it manufactures. Headquartered in Norway with operational headquarters in Singapore, REC also has regional hubs in North America, Europe, and Asia-Pacific.

Datasheet_REC_460W-Alpha-Pure-RX.pdf

Download

Product Specifications

Cell type:	80 half-cut REC bifacial, heterojunction cells with lead-free, gapless technology
Glass:	3.2 mm solar glass with anti-reflective surface treatment in accordance with EN12150
Backsheet:	Highly resistant polymer (black)
Frame:	Anodized aluminum (black)
Junction box:	4-part, 4 bypass diodes, lead-free IP68 rated, in accordance with IEC62790
Connectors:	Stäubli MC4 PV-KBT4/KST4 (4mm²) in accordance with IEC 62852, IP68 only when connected
Cable:	4 mm² PV wire, 1.7m + 1.7 m in accordance with EN50618
Dimensions:	1728 x 1205 x 30 mm (2.08 m²)
Weight:	22.7 kg
Origin:	Made in Singapore
Power Output - PMAX (Wp)	460
Watt Class Sorting - (W)	0/+10
Nominal Power Voltage - VMPP	54.9 V
Nominal Power Current - IMPP	8.38 A
Open Circuit Voltage - VOC	65.3 V
Short Circuit Current - ISC	8.88 A
Power Density (W/m²)	221
Panel Efficiency (%)	22.1
Power Output - PMAX (Wp)	350
Nominal Power Voltage - VMPP	51.7 V
Nominal Power Current - IMPP	6.77 A
Open Circuit Voltage - VOC	61.6 V
Short Circuit Current - ISC	7.17 A
Operational temperature:	-40°C - +85°C
System voltage:	1000 V
Test load (rear):	- 4000 Pa (407 kg/m²)
Max series fuse rating:	25 A
Max reverse current:	25 A
