Victron 100/20 SmartSolar MPPT Controller (Up to 48V)

https://www.springers.com.au/web/image/product.template/3550/image_1920?unique=7e6f193
(0 reviews)

100 V / 20 A maximum power point tracking solar charge controller for 12 - 48 V systems

$ 123.07 - Inc GST 123.07 AUD $ 123.07 Tax Included

Not Available For Sale

($ 123.07 / Unit)
  • Brand

This combination does not exist.

You have already submitted a query for this product today.
In stock
In stock
In stock
Contact Us
Brand: Victron
VICTRON
Terms and Conditions
30-day money-back guarantee
Ships in 2-3 Business Days (online only products may differ)
Solar Controllers, MPPT Charge Controllers, Solar Controllers, MPPT Charge Controllers
SCC110020160R

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

Victron 100/20 SmartSolar MPPT Controller (Up to 48V)



Features

  • Maximum power point tracking solar charge controller
  • Built-in Bluetooth for ease of programming & monitoring
  • 100 V
  • 20 A
  • Suitable for 12 - 48 V systems
  • Internal temperature sensor
  • Direct communication port for wired data connection
  • Over-temperature sensor
  • Flexible charge algorithm
  • VE.Direct port
  • Intelligent battery management
  • Programmable battery charge algorithm
  • Additional SmartSolar LCD display available

Where to use it

A Victron SmartSolar MPPT charge controller is used in off-grid solar power systems to maximise energy harvest, particularly in mobile applications like RVs, boats, and campervans, or remote, off-grid cabins.

Engineered for mobile life, they handle vibration and provide efficient charging for 12V - 48V systems. Its built-in Bluetooth allows for easy monitoring via the VictronConnect app, making it ideal for systems with variable shading or varying light conditions.


Dimensions

Width
131 mm
Height
100 mm
Depth
60 mm
Weight
0.65 kg

Safety features

  • EN/IEC 62109-1
  • UL 1741
  • CSA C22.2
  • IP43 rated

Warranty

  • 5-year warranty
  • Access to Springers Solar's warranty support team
  • Authorised Victron dealer

Applications

4WD
4WD
RV
RV's
Caravan
Caravans
Off-Grid Systems
Off-Grid Systems
Tiny Houses
Tiny Houses
Cabins
Cabins

About Victron

Victron Energy has a strong, unrivalled reputation for technical innovation, reliability, and build quality. Their products are widely considered to be a professional choice for independent electric power. Efficiently combining two or more distinct power sources is what they do best. Their products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.

Specifications

Brand Victron
Comparison_Victron Charge Controllers Overview-EN.pdf
Download
Manual_MPPT_solar_charger_manual-pdf-en.pdf
Download
Datasheet_SmartSolar-charge-controller-MPPT-75-10,-75-15,-100-15,-100-20_48V-EN.pdf
Download

​Product Specifications


Battery voltage (auto-select)
12 / 24 / 48 V
Rated charge current
20 A
Nominal PV power, 12V
290 W
Nominal PV power, 24V
580 W
Nominal PV power, 48V ​1160 W
Max. PV short circuit current
20 A
Automatic load disconnect
 Yes
Max. PV open circuit voltage
100 V
Peak efficiency
98 %
Self-consumption – load on
26 / 20 / 19 mA
Self-consumption – load off
10 / 8 / 7 mA
Charge voltage 'absorption'
14.4 V / 28.8 V / 57.6 V (adj.)
Charge voltage 'float'
13.8 V / 27.6 V / 55.2 V (adj.)
Charge algorithm
 multi-stage adaptive
Temperature compensation
 -16 mV / °C resp. -32 mV / °C
Max. continuous load current
20 A / 20 A / 1 A
Low voltage load disconnect
11.1 V / 22.2 V / 44.4 V or 11.8 V / 23.6 V / 47.2 V or Battery Life algorithm
Low voltage load reconnect
13.1 V / 26.2 V / 52.4 V or 14 V / 28 V / 56 V or Battery Life algorithm
Protection
Output short circuit / Over-temperature
Operating temperature
-30 to +60 °C (full rated output up to 40 °C)
Humidity
95 %, non-condensing
Data communication port
VE.Direct
Colour
Blue (RAL 5012)
Power terminals ​6 mm² / AWG10
Protection category
IP43 (electronic components), IP22 (connection area)
Weight ​0.65 kg
Dimensions
100 x 131 x 60 mm
Safety
EN/IEC 62109-1, UL 1741, CSA C22.2

Accessory Products

[ASS030530010] Victron VE.Direct to USB Interface
VICTRON
Victron VE.Direct to USB Interface
$ 41.98 $ 41.98 41.98 AUD
Tax Included
SKU: ASS030530010
[ASS030530209] Victron VE.Direct Cable (0.9m)
VICTRON
Victron VE.Direct Cable (0.9m)
$ 17.95 $ 17.95 17.95 AUD
Tax Included
SKU: ASS030530209
[SCC900500000] Victron MPPT Control (cable not included)
VICTRON
Victron MPPT Control (cable not included)
$ 87.12 $ 87.12 87.12 AUD
Tax Included
SKU: SCC900500000
[SCC950140000] Victron MPPT Wirebox-S 100-20
