Sungrow AC Type II EV Charger (AC22E-01)

Sungrow AC charger for electric vehicles AC22E-01

Sungrow AC Type II EV Charger (AC22E-01)

(0 review)

Features:
• Type 2 EV Charger
• 11kW or 22kW, AC Charging
• 5m Cable

$ 1,190.00 - Inc GST 1190.0 AUD $ 1,190.00

This combination does not exist.

ADD TO CART Buy now

SUNGROW

Shipping information

30-day returns & refunds

Ships from Brisbane

Category: EV Chargers, EV Chargers

Sungrow AC Type II EV Charger

Features:

Type 2 EV Charger
11kW or 22kW, AC Charging
5m Cable
IP65 Rated for Indoor & Outdoor Use
Beyond Charging with Sungrow Hybrid Solution
Load Management & Balancing with Sungrow Smart Meter
Integrated DC Fault Current Detection
OCPP 1.6J Communication
Multiple Charging Modes with Sungrow Hybrid Solution

Sungrow's AC EV Charger is both reliable and versatile, and is compatible with Sungrow single-phase and three-phase solutions. It features a Type 2 charging plug and a 5-meter charging cable. The charger includes integrated 6mA DC fault detection for enhanced safety. It can be easily managed through the iSolarCloud portal and includes OCPP 1.6J communication capabilities.

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Sungrow:

Sungrow Power Supply Co., Ltd. is one of the world’s most bankable inverter brands with over 405 GW installed worldwide as of June 2023. Founded in 1997 by University Professor Cao Renxian, Sungrow is a leader in the research and development of solar inverters with the largest dedicated R&D team in the industry and a broad product portfolio offering PV inverter solutions and energy storage systems for utility-scale, commercial & industrial, and residential applications, as well as internationally recognized floating PV plant solutions, NEV driving solutions, EV charging solutions and renewable hydrogen production systems. With a strong 26-year track record in the PV space, Sungrow products power over 150 countries worldwide.

Datasheet_DS_20241217_AC22E-01_V4_EN.pdf

Download

Product Specifications

Sungrow AC Type II EV Charger (AC22E-01)
AC Input & Output
Grid Voltage	3P/N/PE, 230 / 400V
Nominal Grid Frequency	50 / 60Hz
Earthing System	TT / TN
Max. Input Current	32A
Standby Self-Consumption	< 6.5W
AC Output
Max. Charging Power	22kW or 11kW at 3-Phase Connection (configurable) or 7.4kW at 1-Phase Connection
Max. Charging Voltage	230 / 400V
Max. Charging Current	32A / 16A (configurable)
Protection & Function
Integrated Fault Current Detection	DC 6mA
Compatibility with External Residual-Current Devices	External RCBO required, Type A or Type B according to IEC 62955
Overload Protection	Yes
Overtemperature Protection	Yes
Surge Protection	Yes
Ground Fault Monitoring	Yes
ALM (Adaptive Load Monitoring)	Yes
Automatic Phase Switching	Yes
User Interface
Display	LED Indicator and App
Authentication	Plug & Play / RFID Card / iSolarCloud App / iEnergy Charge App
Firmware Update	OTA
RFID System	Mifare ISO 14443 A
Energy Metering	MID-certified meter (optional)
Metering Accuracy	Class B
Charging Mode	OCPP / EMS by iEnergy Charge / Eco Charging / Fast Charging / Scheduled Charging / Customised Charging by iSolarCloud
Communication Interface	RS485 (to Sungrow Inverter) / WLAN / Ethernet / 4G
Communication Protocol	OCPP 1.6J
Mechanical Data
Dimensions	214 x 346 x 125mm
Weight	< 6.65kg
Installation Method	Wall-Mounting (default) or Stand Column (optional)
AC Cable Specification	Cross-section up to 5 * 10mm²
Charging Cable Length	5m / 7m (optional)
Charging Connector	Type 2
Environmental Data
Enclosure Rating	IP65
Mechanical Impact Protection	IK10
Operating Ambient Temperature Range	-30 ~ +50°C
Allowable Relative Humidity Range	5% ~ 95% (non-condensing)
Max. Operating Altitude	3000m
Cooling Method	Natural Convection
General Data
Certifications	CE, CB, UKCA, RCM, ADQCC, MoIAT, PEA
Compliance	EN 300 328, EN 300 330, EN 301 489-1 / 3 / 17 / 5 2, EN 301 908-1 / 13, EN 50663, EN 50665, EN IEC 61851-1, EN IEC 61851-21-2, EN IEC 62311, EN 62479
