Sungrow AC Type II EV Charger (AC22E-01)
Sungrow AC charger for electric vehicles AC22E-01
Sungrow AC charger for electric vehicles AC22E-01
Sungrow AC charger for electric vehicles AC22E-01
Sungrow AC Type II EV Charger (AC22E-01)
Sungrow AC charger for electric vehicles AC22E-01
Sungrow AC charger for electric vehicles AC22E-01
Sungrow AC charger for electric vehicles AC22E-01

Sungrow AC Type II EV Charger (AC22E-01)

https://www.springers.com.au/web/image/product.template/18504/image_1920?unique=fdaffb0

Features:
• Type 2 EV Charger
• 11kW or 22kW, AC Charging
• 5m Cable

$ 1,090.00 - Inc GST 1090.0 in stock AUD $ 1,090.00

$ 1,090.00

Not Available For Sale

    This combination does not exist.

    Contact Us
    SUNGROW
    SUNGROW
    ANL050
    EV Chargers EV Chargers

    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days

    Sungrow AC Type II EV Charger

    Features:

    • Type 2 EV Charger
    • 11kW or 22kW, AC Charging
    • 5m Cable
    • IP65 Rated for Indoor & Outdoor Use
    • Beyond Charging with Sungrow Hybrid Solution
    • Load Management & Balancing with Sungrow Smart Meter
    • Integrated DC Fault Current Detection
    • OCPP 1.6J Communication
    • Multiple Charging Modes with Sungrow Hybrid Solution


    Sungrow's AC EV Charger is both reliable and versatile, and is compatible with Sungrow single-phase and three-phase solutions. It features a Type 2 charging plug and a 5-meter charging cable. The charger includes integrated 6mA DC fault detection for enhanced safety. It can be easily managed through the iSolarCloud portal and includes OCPP 1.6J communication capabilities.


    Applications

    Marine
    RV's
    Caravans
    Off-Grid Systems
    Tiny Houses
    Cabins

    More about Sungrow:

    Sungrow Power Supply Co., Ltd. is one of the world’s most bankable inverter brands with over 405 GW installed worldwide as of June 2023. Founded in 1997 by University Professor Cao Renxian, Sungrow is a leader in the research and development of solar inverters with the largest dedicated R&D team in the industry and a broad product portfolio offering PV inverter solutions and energy storage systems for utility-scale, commercial & industrial, and residential applications, as well as internationally recognized floating PV plant solutions, NEV driving solutions, EV charging solutions and renewable hydrogen production systems. With a strong 26-year track record in the PV space, Sungrow products power over 150 countries worldwide.

    Datasheet_DS_20241217_AC22E-01_V4_EN.pdf
    Download

    Product Specifications

    Sungrow AC Type II EV Charger (AC22E-01)
    AC Input & Output

    Grid Voltage3P/N/PE,  230 / 400V
    Nominal Grid Frequency50 / 60Hz
    Earthing SystemTT / TN
    Max. Input Current
    		32A
    Standby Self-Consumption< 6.5W
    AC Output
    Max. Charging Power
    		22kW or 11kW at 3-Phase Connection (configurable)   or   7.4kW at 1-Phase Connection
    Max. Charging Voltage
    		230 / 400V
    Max. Charging Current
    		32A / 16A (configurable)
    Protection & Function
    		​
    Integrated Fault Current Detection​DC 6mA
    Compatibility with External Residual-Current Devices​External RCBO required, Type A or Type B according to IEC 62955
    Overload Protection​Yes
    Overtemperature Protection​Yes
    Surge Protection​Yes
    Ground Fault Monitoring​Yes
    ALM (Adaptive Load Monitoring)​Yes
    Automatic Phase Switching​Yes
    User Interface​​
    Display​LED Indicator and App
    Authentication
    		Plug & Play / RFID Card / iSolarCloud App / iEnergy Charge App
    Firmware Update​OTA
    RFID SystemMifare ISO 14443 A
    Energy Metering​MID-certified meter (optional)
    Metering AccuracyClass B
    Charging Mode​OCPP / EMS by iEnergy Charge / Eco Charging / Fast Charging / Scheduled Charging / Customised Charging by iSolarCloud
    Communication Interface​RS485 (to Sungrow Inverter) / WLAN / Ethernet / 4G
    Communication ProtocolOCPP 1.6J
    Mechanical Data​
    Dimensions214 x 346 x 125mm
    Weight< 6.65kg
    Installation MethodWall-Mounting (default)  or  Stand Column (optional)
    AC Cable SpecificationCross-section up to 5 * 10mm²
    Charging Cable Length5m / 7m (optional)
    Charging ConnectorType  2
    Environmental Data​
    Enclosure RatingIP65
    Mechanical Impact ProtectionIK10
    Operating Ambient Temperature Range-30 ~ +50°C
    Allowable Relative Humidity Range5% ~ 95% (non-condensing)
    Max. Operating Altitude3000m
    Cooling MethodNatural Convection
    General Data​
    CertificationsCE, CB, UKCA, RCM, ADQCC, MoIAT, PEA
    ComplianceEN 300 328, EN 300 330, EN 301 489-1 / 3 / 17 / 5 2, EN 301 908-1 / 13, EN 50663, EN 50665,
    EN IEC 61851-1, EN IEC 61851-21-2, EN IEC 62311, EN 62479
