Fronius Symo GEN24+ 10kW Solar Inverter

Symo GEN24 Plus 10.0 Inverter

Input Data

Number of MPP Trackers

2

DC Input Voltage Range

80-1,000V

Nominal Input Voltage

610V

Feed-in Start-up Input Voltage

80V

Usable MPP Voltage Range

80-800V

MPPT 1

Maximum Usable Input Current

25A

Maximum Short Circuit Current, Module Array

40A

Number of DC Connections

2

Maximum Usable DC Output

10,300W

Maximum PV Generator Output

12.5kW Peak

Nominal AC Output Current @380V AC

15.2A

MPPT 2

Maximum Usable Input Current

12.5A

Maximum Short Circuit Current, Module Array

20A

Number of DC Connections

1

Maximum Usable DC Output

6,000W

Maximum PV Generator Output

7.5kW Peak

Nominal AC Output Current @400V AC

14.5A

Total

Total Maximum Usable DC Output

10,300W

Total Maximum PV Generator Output

15kW Peak

Output Data

AC Rated Power

10,000W

Apparent Power

10,000VA

Maximum Output Power

10,000VA

Grid Connection (Voltage Range)

3 ~ NPE 400V / 230V or 3 ~ NPE 380V / 220V (+20% / -30%)

Frequency (Frequency Range)

50 Hz / 60 Hz (45 - 65 Hz)

Total Harmonic Distortion

< 3%

Power Factor

0.7 - 1 ind. / cap.

Output Data PV Point

Nominal Output Power PV Point

3000VA

PV Point Grid Connection

1 ~ NPE 220V / 230V

Switchover Time

< 23 sec.

Output Data Full Backup

Nominal Output Power Full Backup

10,000VA

Grid Connection Full Backup

3 ~ NPE 400V / 230V or 3 ~ NPE 380V / 220V

Switching Time

< 35 sec.

Battery Connection

Number of DC Inputs

1

Maximum Input Current (IDC Max)

22A

DC Input Voltage Range (UDC Min - UDC Max)

160-531V

DC Battery Connection Technology

1x BATT+ and 1x BATT- push-in spring terminals 2.5 - 10 mm²

Maximum DC Input/Output Power

10,300W

Maximum Charging Power for AC Coupling

10,000W

Compatible Batteries

BYD Battery-Box Premium HVS/HVM, LG FLEX

Efficiency

Maximum Efficiency

98.2 %

MPP Adaptation Efficiency

> 99.9 %

Protective Devices

DC Insulation Measurement

Integrated

Overload Behaviour

Operating Point Shift. Power Limitation

DC Disconnector

Integrated

Reverse Polarity Protection

Integrated

Interfaces

Wi-Fi / 2x Ethernet LAN

Fronius Solar.web, Modbus TCP SunSpec, Fronius Solar API (JSON)

6 Inputs and 6 Digital In/Out

Interface to ripple control receiver

Emergency Shutdown (WSD)

Integrated

Datalogger and Web Server

Integrated

2x RS485

Modbus RTU SunSpec (third-party provider / Fronius Smart Meter, Battery (GEN24 Plus), Fronius Ohmpilot

General Data

Dimensions

595 x 529 x 180mm

Weight

28.5kg

Degree of Protection

IP66

Safety Class

1

Night-time Consumption

<10

Overvoltage Category (DC / AC)

2 / 3

Inverter Concept

Transformerless

Cooling

Active Cooling Technology

Installation

Indoor and outdoor installation

Ambient Temperature Range

–25°C to +60°C

Permissible Humidity

0 - 100 %

Noise Emissions

<36

Maximum Altitude

3,000 m Unrestricted Voltage Range / 4,000 m Restricted Voltage Range

DC PV Connection Technology

3 × DC+ and 3 × DC- push-in tension clamp terminals 2.5 - 10 mm²

AC Connection Technology

5-pin AC push-in tension clamp terminals 1.5 - 10 mm², 3-pin backup power push-in tension clamp terminals 1.5 - 10 mm², 5 × PPE screw terminals 2.5 - 16 mm²

Certificates and Compliance with Standards

IEC 62109, IEC 62116, IEC 61727, IEC 62909, VDE 0126, VDE AR-N4105, AS/NZS 4777.2, EN 50549, CEI 0-21, G98/G99, R25

Backup Power Functions

PV Point

Production Country

Austria

Life Cycle Assessment

In accordance with ÖNORM EN ISO 14040 and 14044 (checked by employees from Fraunhofer IZM)
