| Number of MPP trackers | 2 |
| Max. input current (Idc max) | 25 / 12,5 A |
| Max. short circuit current, module array* | 40,0 / 20,0 A |
| DC input voltage range (Udc min - Udc max) | 80-1000 V |
| Feed-in start voltage (Udc start) | 80 V |
| Nominal input voltage (Udc,r) | 610 V |
| MPP voltage range (Umpp min - Umpp max) | 278-800 V |
| Usable MPP voltage range | 80-800 |
| Number of DC connections | 2/1 |
| Max. PV generator power (Pdc max) | 15 kWpeak |
| AC nominal output (Pac,r) | 10 kW |
| Max. output power (Pac max) | 10 kVA |
| Max. grid power demand | 10.000 VA |
| Max. AC output current | 16,4 A |
| Grid connection (Uac,r) | 3~NPE 400/230, 3~NPE 380/220 V |
| AC voltage range (Umin - Umax) | 154 - 280 V |
| Frequency (fr) | 50 / 60 Hz |
| Frequency range (fmin - fmax) | 45 - 66 Hz |
| Total harmonic distortion | <3% @Pnom (230/400VAC 50Hz) |
| Power factor (cos φac,r) | 0,7-1 ind,/cap, |
| Back-up power | 1~NPE 220 V / 230 V |
| Nom. AC output current (380VAC) | 12,1 A |
| Nom. output current (400VAC) | 11,6 A |
| Width | 529 mm |
| Height | 595 mm |
| Depth | 180 mm |
| Weight | 23,38 kg |
| Weight incl. packaging | 28,5 kg |
| Degree of protection | IP66 |
| Protection class | 1 |
| Overvoltage category (DC / AC) 1) | 2 / 3 |
| Night-time consumption | <10 W |
| Inverter design | Transformerless |
| Cooling | Regulated air cooling |
| Installation | Indoor and outdoor installation |
| Ambient temperature range | -25°C - +60°C |
| Permitted humidity | 0 - 100% |
| Max. altitude 2) | 3000m / 4000m |
| DC PV connection technology | 3x DC+ and 3x DC- push-in spring terminals 2.5 - 10 mm² |
| AC connection technology | 5 pole AC push-in spring terminals 1.5 - 10 mm² 3 pole backup power push-in spring terminals 1.5mm² - 10mm² 5x PE-screw terminals 2.5 - 16 mm² |
| AC connection technology | PV Point |
| Certificates and compliance with standards | IEC 62109, IEC 62116, IEC 61727, IEC 62909, VDE 0126, VDE AR-N4105, AS/NZS 4777.2, EN 50549, CEI 0-21, G98/G99, R254) |
| Sound emissions | 47 dB(A) |
| Interference emission class | B |
| Max. efficiency (PV - grid) | 98,2 % |
| European efficiency (ηEU) | 97,9 |
| η at 5% Pac,r 3) | 95,1 |
| η at 10% Pac,r 3) | 97 |
| η at 20% Pac,r 3) | 97,9 |
| η at 25% Pac,r 3) | 98 |
| η at 30% Pac,r 3) | 98,1 |
| η at 50% Pac,r 3) | 98,2 |
| η at 75% Pac,r 3) | 98,1 |
| η at 100% Pac,r 3) | 98 |
| MPP adaptation efficiency | >99,9 % |
| DC insulation measurement | Yes |
| Overload behaviour | Operating point shift, Power limitation |
| DC disconnector | Yes |
| DC Reverse polarity protection | Yes |
| WLAN / 2x Ethernet LAN | Fronius Solar.web, Modbus TCP SunSpec, Fronius Solar API (JSON) |
| 6x digital in/out + 6x digital in | Interface to ripple control receiver, energy management |
| Emergency stop (WSD) | Yes |
| Datalogger and web server | Included |
| 2x RS485 | Modbus RTU SunSpec (third-party supplier) / Fronius Smart Meter, battery, Fronius Ohmpilot |
| Max continuous output power | 3000 VA |
| Nom. output current (Iac max) | 13 A |
| Grid connection | 1 ~ NPE 220 V / 230 V |
| Frequency | 53 Hz / 63 Hz |
| Max. switchover time PV-Point | 20 s |
| Frequency in backup power mode | 53 Hz |
