Enerdrive B-TEC 12V 200Ah Battery, 40DC, 40AC & ePRO+

BTEC LIFEPO4 12V 200AH AC-DC BUNDLE PLUS MONITOR

EPOWER 12V 200AH BTEC DC40, AC40 & EPRO+

Enerdrive B-TEC 12V 200Ah Battery, 40DC, 40AC & ePRO+

(0 review)

Epl200bt-g2 12v 200ah enerdrive lithium iron phosphate (lifepo4) battery • built in bluetooth monitoring • en31240 epower 240v 40a charger • en3dc40+ epower dc-dc charger • enerdrive epro+ battery monitor • 5 year warranty

$ 3,599.00 - Inc GST 3599.0 AUD $ 3,599.00

Brand

This combination does not exist.

ADD TO CART Buy now

Brand: Enerdrive

ENERDRIVE

Category: DCDC Chargers, DCDC Chargers

Enerdrive PWM 12V solar controller:

For maintenance free protection of your batteries and solar panels the controllers regulated output will prevent batteries overcharging. Load Disconnect (LD) feature will protect batteries from being over discharged. Available as 10A or 20A

Enerdrive Solar Charge Controller benefits include:

- Protects battery from overcharge and discharge

- Only for 12 Volt solar panels and batteries

- Handles up to 20 Amps of Array Current

- Handles up to 350 Watts of solar power

- Maintenance free protection of your solar panel and batteries

- Maintains battery voltage

- Maintain 12V batteries in a fully charged state

Product Features:

- LED status indicator provides quick reference to Charger, Battery and load status

- Selectable battery type

- Temperature compensation

- High precision on voltage set point

- Wall mountable

Applications

Marine

RV's

Caravans

Off-Grid Systems

Tiny Houses

Cabins

More about Enerdrive:

Enerdrive Pty Ltd has been providing independent power systems to the Australian market since 1996. Starting as Advance Trident Limited in 2003 and predominantly servicing the marine industry, ATL saw the huge growth potential in the mobile and recreational vehicle market soon after, and in 2008 ATL Limited morphed into Enerdrive. In recent times Enerdrive has embarked on its own manufacturing program. They saw the need to control their own destiny and produce high-end products that the Australian marketplace was demanding. This program has led to Enerdrive manufacturing their own range of ePOWER AC Battery Chargers & DC2DC Battery Chargers along with Lithium battery systems.

Specifications

Brand

Enerdrive

Manual_B-TEC-EPL-200BT-12V-G2-Manual_Rev-2.0_compressed.pdf

Download

Datasheet_Enerdrive-B-TEC-200AH-12V-G2-Data-Sheet.pdf

Download

Datasheet_DC2DC-Plus-A4-2pp-WEB-01.pdf

Download

Manual_DC2DC-PLUS-User-Manual-WEB-1.0.pdf

Download

Datasheet_ePOWER-Charger-Brochure_2022_WEB.pdf

Download

Manual_AC-Charger-Combination-Manual-Rev-5.5_2023_WEB.pdf

Download

Datasheet_ePRO-plus-brochure-4ppA4-WEB.pdf

Download

Manual_ePRO-Plus-User-Manual-Rev-1.03-WEB.pdf

Download

Enerdrive-Warranty-Policy-2020.pdf

Download

Product Specification

B-TEC 12V 200Ah G2 Lithium Battery

Model -	EPL-200BT-12V G2
Nominal Voltage	12.8V
Nominal Capacity	200Ah
Cycle Life (DOD – 80% under controlled conditions)	≥ 2000 Cycles
Battery Charge Temperature	0 ̴ 45°C
Normal Charge Voltage CV/CC*	14.20 ̴ 14.60V
Standby (Float) Voltage	13.50 ̴ 13.80V
Maximum Charge Current	150A @ 25°C for 30mins
Recommended Charge Current For Maximum Life, Charge in the lower amperage range	40~100A
Battery Discharge Temperature	-20 ̴ 60°C
Battery Output Voltage Range	11.00 ̴ 14.60V
Maximum Discharge/Pulse Current	200A @ 25˚C ±5˚C for 30 mins
Pulse Discharge Current	450A for 1.0s
Discharge Cut-off Voltage	≤11.20V
Circuit Protection	The battery is supplied with a LiFePO4 Battery Management System BMS that can monitor and optimize each single prismatic cell during charge & discharge,to protect the battery pack from overcharge, over discharge & short circuit. Overall, the BMS helps to ensure safe and accurate operation of the battery.
Over-charge Protection Per Cell	3.90V ± 0.03V
Over-charge Release Per Cell	3.60V ± 0.05V
Over-charge Release Method	Discharge below release voltage
Over-discharge Protection Per Cell	2.80V ± 0.05V
Over-discharge Release Per Cell	3.20V ± 0.05V
Over-discharge Release Method	Apply Charge/Voltage ≥12.8V
Battery Manual Reset Button	Yes
Discharge Over Current	220A for 30s – 450A for 1s
Protection Reset Time	Approx 10s Auto Release
Over Current Release Method	Disconnect Load
Battery Discharge Over Temperature	Protection to 65°C ± 5°C Release at 50°C ± 5°C
Battery Charge Over Temperature	Protection to 55°C ± 5°C Release at 45°C ± 5°C
Short Circuit Protection	Auto release after 5s
Length	505mm
Width	172.5mm
Height	265mm
Weight	Approx 25.0 Kg
Case Construction	Hi Impact ABS Plastic
Temperature & Humidity Range	≤ 30 days -20°C ̴ 60°C, 5 ̴ 75% RH ≥ 90 days -10°C ̴ 45°C, 5 ̴ 75% RH
Self-discharge Rate	≤ 3% Per Month

ePOWER 12V 40A Battery Charger

Model -	EN31240
Output Current (Maximum)	40A
Charge	14.2 – 15.5 V
Float	13.4 – 13.8 V
– Equalize	16.0 V
Charging Control	Four stages (Bulk/Absorption/Float/Maintenance)
	Two stages (Bulk/Absorption)
	Constant Power Supply (Program setting)
	Priority Battery Bank Charging
DC Output Bank	Three (1 fully independent, 2 common with diode isolation)
Selectable Battery Type	Gel, AGM, Flooded, Lithium, Program
Standby Current	< 2 mA
AC Input Voltage (Nominal)	90 to 265 VAC
AC Input Operating Range	207-265 Vac (3.8 A Max)90 – 125 Vac (7.7 A Max)
AC Input Frequency Range	47 – 63 Hz
Power Consumption	700W (Full Load)
Power Factor Correction	Yes
Charger Efficiency	> 82%
Reverse Polarity	Yes, (with user replaceable fuse/s)
Over Charge	Yes, unit shutdown
Over Temperature	Yes, unit de-rated and shutdown
Output Short Circuit	Yes, (with user replaceable fuse/s)
Cooling	Forced air ventilation (thermo controlled fan)
Temperature Setting	Hot, Normal, Cold (no sensor connected)
Battery Temp Sensor Port	RJ12 (standard battery temp. sensor supplied)
LCD Display (with back light)	Charging status, Battery Voltage, Output Current & Fault Codes.
AC Input Connection	IEC with Supplied 1.2M Power Lead
DC Output Connection	Heavy Duty Terminal (3 banks) – Pan Heads 6mm Thread
DC Output Ground	Single Heavy Duty Common Ground Stud
Storage Range	-40° to 70° C
Operating Range	-20° to 60° C
Humidity	5-95%, relative humidity non-condensing
Ingress Protection	IP32 (Basic drip proof in vertical orientation)
	Base Unit Weight and Dimensions
Weight: (kg)	2.6
Dimension: (mm) L x W x H	295 x 206 x 86
Optional Accessories	Remote Digital Display / Enerdrive Part Number EN3REM
Regulatory Compliance	Complies with AS/NZS 60335.2.29 Including Australian deviations.

12V 40A DC2DC+ Battery Charger

Model -	EN3DC40+
Output Voltage	12V Nominal (8.0V min)
Output Current (Maximum)	40A ~ 50A
Output Power	775W
Charger DC Output (CH1):
Selectable Battery Type	Gel, AGM, Flooded, Lithium, Program
Charger Voltage Range	13.8V – 15.5V
Float Voltage Range	13.0V – 13.8V
Charger Current (User Selectable)	5/10/15/20/25/30/35/40/45/50A (default 40A)
Equalize Voltage (Flooded Battery)	15.5V
Equalize Charging Current	10% of Bulk Current Setting
Charging Control	2 stage / 3 stage selectable (Default 3 stage)
DC Output Bank	Single
Current draw from CH1 when not in use	< 50mA
Battery Temperature Setting	Low/ Normal/ High (Battery Temperature Sensor Standard)
Efficiency	95%
INPUT Rating (CH2 – MPPT Solar)
Input Voltage	14.5 – 45VOC
Maximum Input	≤ 23V input, 500W (600W allowable) ≥37.5V-45V input, 750W (800W allowable)
INPUT Rating (CH3 – Start/Alternator)
Input Voltage	10.5 – 16VDC / 21 – 32VDC
Height x Width x Depth	242mm x 172mm x 74mm
Unit Weight	1.85 Kg
Shipping Weight	2.17 kg

ePRO Plus Battery Monitor

Model -	ePRO Plus (Part No: EN55050)
Supply voltage range	7..70Vdc
Supply current (@ 12V/ 24V/48V)	10mA / 6mA / 5mA
Input voltage range main battery (+B1)	7..70Vdc1)
Input voltage range second & third battery (+B2, +B3)	1..70Vdc
Input current range	-600..+600A2)
Battery capacity range	10..10000Ah
Operating temperature range	-20..+50°C
Storage temperature range	-30..+70°C
Voltage (0..70V)	± 0.01V
Current (0..10A)	± 0.01A
Current (10..100A)	± 0.1A
Current (100..600A)	± 1A
State of Charge (0..100%)	± 1%
Time remaining (0..24hrs)	± 1min
Time remaining (24..240hrs)	± 1hr
Amphours (0..10000Ah)	± 0.01Ah..10Ah (variable)
Power (0..42kW)	± 0.01W..1kW (variable)
Temperature (-20°C..+50°C)	± 0.5°C
Voltage measurement accuracy	± 0.3%
Current measurement accuracy	± 0.4%
Footprint	100 x 100mm
Base height	24.0mm
Total height	64.5mm
Weight	290grams
Front panel	Ø 64.0mm
Body diameter	Ø 51.5mm
Total depth	36.0mm
Weight	70grams
Protection class	IP20 (CDU front panel only IP65)
Standards	CE certified (EMC Directive 2014/30/EU) including EN50498 Automotive EMC
