Simarine Battery Shunt 500A 2V 2R 1T
https://www.springers.com.au/shop/si-sc503-simarine-battery-shunt-500a-2v-2r-1t-14221 https://www.springers.com.au/web/image/product.template/14221/image_1920?unique=0662eddBattery shunt to suit simarine pico monitors • 2x volt 2x resistance 1x temperature
Brand: Simarine |
SIMARINE
COMBO QUADRO SHUNT MODULE:
Innovative combination of shunt and tank level module. SC503 is a high precision combo shunt for PICO battery monitor with 2x voltage, 2x temperature, 1x socet for temperature sensor with JST connector and 1x current sensor up to 500A for up to 75V systems.
It can be used for monitoring current draw of heavy consumers (inverters, bow and stern thrusters, anchor winches) and current generators (shore power chargers and solar panels). Additionally, it allows monitoring tanks for fuel, fresh and grey water.
Applications
Marine
RV's
Caravans
Off-Grid Systems
Tiny Houses
Cabins
More about Simarine:
Founded on a belief that electronic devices should be easy to understand and use, Simarine provides energy-efficient, user-friendly products built sustainably with high-quality materials. Their state-of-the-art electronic solutions for caravans, campervans, motorhomes and marine applications are a staple of the industry. Their mission is to provide lovers of the great outdoors and seekers of breathtaking views with accurate and reliable data on, and control over, their batteries, tank levels, temperatures, individual consumers and generators, and much more. All in an easy-to-understand format.
Specifications
Brand | Simarine |
Product Specification
Operating Voltage Range | 6 - 35V |
Operating Temperature Range | -20 +70'C |
Operating Power Consumption (12V) | 1.2mA |
Max Continuous Current | 500A |
Peak Current (<1min) | 1000A |
Peak Current (<5min) | 700A |
Measuring Current Range | 0.01-700A |
Measuring Current Accuracy | ±0.6% |
Measuring Current Resolution | 0.01A |
Voltage Input Range | 0 - 75V |
Voltage Input Accuracy | ±0.2% |
Voltage Input Resolution | 1mV |
Sampling Rate (Current & Voltage) | 100 ms |
Resistance Input Range | 0 Ohm - 65 kOhm |
Resistance Input Accuracy | ±3.0% |
Temperature Sensor Range | -15 +80'C |
Temperature Sensor Accuracy | ±3.0% |
Battery Connectivity | Up to 1 |
Temperature Sensor Connectivity | Up to 3 |
Voltage Sensor Connectivity | Up to 2 |
SiCOM RJ9 Socket Connectivity | Up to 2 |
Dimensions (LxWxD) | 120 x 120 60mm |
Battery Connection | M10 |
